Features



  1. Constructed of commercial-grade quality components, with forged brass levers and plates
  2. Heavy-duty spring provides a smooth, positive return action of the lever and eliminates droop extending the life of the product
  3. Furniture re-handed by simple relocation of lever using the screw stop block prior to installation
  4. Anti-vandal option available
  5. Suitable for use on fire door assemblies when used with fire-rated locks and latches



Specifications

Material

Forged Brass

Door Type

Timber or Metal

Door Thickness

32mm to 55mm (56mm to 75mm with optional extended screws)

Spindle Size

7.6mm

Compatible locks/latches

Legge 990MF Series mortice locks

Lever to Cylinder Centres

63.5mm

Fixing

Back to back, external plates concealed fixing, screws supplied with

exterior plates only, screw length 75mm, optional extended scew 100mm

MaterialsForged brass
