Features



  1. Key removable outside lever for quick re keying and easy cylinder replacement and keying
  2. Cold rolled steel, machined, threaded hubs and locking nuts prevent loosening of the lockset by bolting chassis to the door
  3. True through-bolting of door prevents lock chassis rotation and disengagement from latch
  4. Stainless steel interlocking spindle design for added strength against excess force when lever is in locked position or latch has been fully retracted
  5. Heavy duty cast mounting plate with specially tapped holes reduces loosening of through-bolting and lockset on the door.



Specifications

Door Thickness

35mm - 48mm

Material

Exposed trim wrought brass. Levers pressure cast zinc

Handing

Reversible

Backset

70mm Standard. 60mm, 95mm and 127mm available

Latchbolt

Brass, 13mm

Cylinder

Brass 6 pin tumbler Schlage 'C' keyway standard
