Features



  1. Suitable for all types of single doors
  2. Can be used in conjunction with an 8827EO surface mounted vertical rod device and 1609 strike for double rebated door applications
  3. For rebated double door applications, the 8827EO should be used in conjunction with an 88EO rim device and 1609 strike
  4. When 88EO is used in conjuctions with 8827EO and 1609 strike on double rebated doors, the minimum stile width is 117mm
  5. Field sizeable to accommodate a range of door openings
  6. Multi-point locking device, with a 16mm throw top and bottom latch.



Specifications

Door Type

All door types

Door Thickness

Combination of fasteners are furnished for surface mounting or through bolting Surface mounted - 19mm minimum Through bolt - 44mm to 57mm

Door Width

600mm minimum, Stile width 111mm minimum with standard 299 strike 100mm minimum with optional 1606 strike

Handling

Reversible

Device Length

1220mm

Device Projection

121mm
