Features



  1. 12/24 VDC output, field selectable with jumper
  2. Designed with high in rush current for powering electrified panic devices
  3. Universal 120 - 240 VAC input
  4. Low voltage DC, regulated and filtered
  5. Electronic power limiting foldback circuit for AC current overload protection
  6. Polarised connectors for distribution boards



Specifications

Function

Battery fuse size 7.5A 32v ATO blade style

Output Voltage

4A @ 12 or 24 VDC Field selectable with jumper Switching supply, 5% regulation, 360mVpp max ripple, Input voltage 120/240 VAC, 50/60 Hz, universal input

AC primary fuse size 6.3A, 250v, 5 x 20mm SLOW-BLOW

Enclosure Grey/Baked Enamel

14” x 12” x 4” (H x W x D) Eight 1⁄2” x 3⁄4” knockouts Hinged cover with lock down screws

Operating Temperature

32° - 120°F (0° - 49°C)

Certifications

UL 294 RoHS FCC Part 15 Class 2

Option

Board compatibility 900-BB: Battery backup 900-BAT: Backup battery pack 900-BBK: Battery backup kit (backup board and battery pack) 900-FA: Fire alarm (must be installed on distribution boards) 900-2RS*: 2 Relay EL panic device control board 900-4R*: 4 Relay output board 900-4RL*: 4 Relay logic board 900-8F*: Fused 8 zone distribution board 900-8P*: PTC 8 zone distribution board
