Features



  1. Rim device has deadlocking latch with 19mm throw
  2. Vertical rod device has deadlocking latches with 16mm throw
  3. Available in 914mm and 1220mm lengths to suit a range of door openings
  4. Vertical rod device suitable for doors up to 2134mm (3050mm-high when fitted with extension rods)
  5. ‘F’ models are fire rated and are not supplied with a dogging (hold open) feature
  6. Optional external trims available for key access



Specifications

Door Type

Timber, Aluminium or Metal

Surface Mounted

19mm minimum; Through bolt: 44mm to 57mm

Stile Width

121mm minimum with standard 299 strike, 100mm minimum with optional 1606 strike

Door Width

914mm length - 673mm minimum*, 1220mm length - 825mm minimum* (* based on standard strike and 13mm stop)

Handing

Reversible

Latch

19mm throw, deadlocking
